Deployment Modes for 5G Compact Core



08th of April 2021





Introduction

5G holds immense potential to transform virtually every industry with its ultrafast speeds, low latency, high bandwidth, and reliability. As healthcare, automotive, manufacturing, entertainment, and a host of other sectors eagerly await the application of next-gen use cases, the race is on for service providers to find the easiest path to rolling out and monetizing the next-gen technology, especially for their enterprise clients. Alepo’s Compact Core facilitates the support of enterprise deployments, particularly those looking for private networks, and it offers a host of flexible options depending on the operator’s unique business requirements.

Alepo’s Compact Core

Most existing 5G networks are powered by 4G core/EPC and 5G RAN (non-standalone 5G or 5G NSA), and since they are dependent on the 4G core, they aren’t true end-to-end 5G networks. Alepo’s new-generation Compact Core, along with the ESS Portal, is set to change that. All elements in the 5G-compliant Compact Core are pre-integrated, ensuring that enterprises can swiftly set up standalone 5G networks (5G SA) that are independent of the 4G core, while also supporting combo deployments over an existing 4G core.

The industrialized Compact Core solution enables service providers to support enterprise and industrial use cases for a small number of subscribers. A complete pre-integrated and self-contained solution, the Compact Core includes the network core and other networking infrastructure, working seamlessly with end devices and the radio access network without impacting or depending on external systems.

The solution comprises AuSF for Authentication, UDM for Authorization, a converged policy combo (PCF + PCRF), and Data Repository for Subscriber Data Management. It also includes an enterprise self-service portal for enterprises to import and efficiently manage all connected devices. (For more details on its features and benefits, read our blog, Envisioning Private 5G Success with Compact Core.)

Compact Core Deployment Modes

Local deployment model

DescriptionBenefitsUse Cases
    The 5G Core (5GC) is deployed on-premise over private cloud or standalone servers. The containerized 5G core network functions (NFs) are deployed on cloud-native infrastructure. It is a completely isolated system with no external inputs or outputs, and all data processing is completed and stored onsite.
  • High security with local control and no outside connection

  • Optimizes OPEX

  • One-box solution

  • Ensures smooth operations and maintenance through support for integrated EMS and PaaS tools

  • Manufacturing

  • Utilities

  • Public safety

  • Smart buildings

  • Education

Hybrid deployment model

DescriptionBenefitsUse Cases
    The User Plan Function (UPF) is deployed on the telco edge or enterprise premise, while the 5G core is deployed on private or public cloud at a centralized location. All devices are connected to a centralized server; the data payload dynamically changes depending on the edge location, helping ensure low latency.
  • Enables low-latency data connectivity

  • The UPF is connected to the 5G Core using a secured tunnel, ensuring failproof security

  • All 5GC NFs are deployed with a minimal resource footprint

  • Enables focus on data control and access, with dedicated communications only where needed

  • Ensures smooth operations and maintenance through support for integrated EMS and PaaS tools
  • V2X (vehicle to everything) tracking

  • Centralized and distributed campus networks

  • 5G network slicing

  • Logistics

Public cloud model

DescriptionBenefitsUse Cases
    The 5G core NFs are deployed on highly distributed public cloud infrastructure, enabling one or more geographic locations both within the operator’s premises as well as in other regions. Supports secure and reliable wireless infrastructure for industrial applications.
  • Reduces network management complexities and ongoing IT maintenance

  • Lowers CAPEX and deployment time

  • Simplifies deployments through automated orchestration and configuration

  • Helps efficiently manage traffic

  • Industrial IoT (IIoT)

  • Manufacturing automation

  • Events

  • 5G AR

  • Base station sites

  • Regional and/or national data centers for edge infrastructure

4G+5G combo model

DescriptionBenefitsUse Cases
    This converged offering for a joint 4G and 5G core supports containerized 4G+5G core NFs that are deployed over cloud-native infrastructure, with support for inter-RAT and intra-RAT mobility.
  • Can be deployed with or without N26 interworking support

  • A one-box solution

  • Helps optimize CAPEX and OPEX

  • Supports integrated EMS and PaaS tools for smooth operations and maintenance
  • For enterprises who want to segregate 4G and 5G cores

  • Network slicing

Business Benefits of Alepo’s Compact Core

Partnering with Alepo for the Compact Core offers a host of advantages for service providers:

  • The solution’s flexibility in deployment is unparalleled, ensuring a low resource footprint no matter what deployment mode an enterprise chooses.
  • The Compact Core leverages cloud-native features to ensure hassle-free, automated, and cost-efficient operations that can be tailored for each enterprise’s unique business requirements.
  • The plug-and-play capability enables enterprises to swiftly launch a private network, bundling in one solution a host of network offerings (broadband, voice, and more). The various open interfaces such as Radio Access Network (RAN) or core network can plug into the operator’s network for wide-area coverage. The solution enables the enterprise to support and control services (like edge computing) and facilitates network management using a network slice.
  • Alepo is an early mover in helping operators implement 5G technology, with many 5GC projects and compact cores deployed. As an end-to-end solutions provider, we leverage our many cross-industry partnerships, build cybersecurity plans, and ensure regulatory compliance in your region of operations, enabling you to realize your operational and business goals so you can focus on helping your enterprise clients do that same.



Begin your next-gen journey today by booking a demo with our 5G solution experts.
